Camper Van CV600
Camper Van
CV600
Let’s go! Everything stowed away. Wardrobes, roof and floor cupboards offer plenty of space for everything you need on holiday.
Spacious bathroom with fixed washbasin.
Isofix for two seats as standard.
The open line of sight creates an enormous sense of space.
Spacious refrigerator that can be opened from the outside.
The overhead storage cupboard offers plenty of space.
Spacious refrigerator that can be opened from the outside.
The open line of sight creates an enormous sense of space.
Isofix for two seats as standard.
Spacious bathroom with fixed washbasin.
The overhead storage cupboard offers plenty of space.
Technical Information CV600
- Standard chassis Fiat Ducato
- Standard engine 2.2 Multijet
- kW (BHP) 103 (140)
- Emission standard Euro 6d
- Tire size 215/70 R 15 C
- Total length (cm) 599
- Total width (cm) 205
- Total height (cm) 270
- Headroom in living area (cm) 190
- Wheelbase (cm) 404
- Mass in running order (kg)* 2768 (2630 - 2906)*
- Manufacturer-specified mass for optional equipment (kg)* 407
- Technically permissible maximum laden mass (kg) * 3500
- Permissible towing capacity, braked, kg 2500
- Trailer load braked (unbraked) (kg) 750
- permitted number of seats (including driver)* 4
- Bed dimension rear L x B (cm) 197 x 157 - 150
- Bed dimension middle L x B (cm) 185 x 105 - 88 OPT
- Berths 2 - 3 OPT
- Refrigerator volume incl. freezer (l) 84
- Heating type Combi 4
- Storage space for gas cylinder with max. 11 kg filling weight 2x 11kg
- Fresh water tank capacity, total/ Fresh water tank capacity at driving filling 100 / 20
- Waste water tank approx. l 90
- Sockets 230 V 3
- Sockets: USB 2
The manufacturer-specified mass for optional equipment is a calculated value for each type and layout that Carado uses to determine the maximum weight available for factory-fitted optional equipment. The limitation of optional equipment is intended to ensure that the minimum pay-mass, i.e. the legally prescribed free mass for baggage and retrofitted accessories, is actually available for the vehicle load capacity of the vehicles delivered by Carado.
The real weight of your vehicle ex works can only be determined when it is weighed at the end of the line. If, in exceptional cases, the weighing shows that the actual load capacity falls below theminimum pay-mass despite limiting the optional equipment due to a permissible weight deviation, we will check together with your trade partner and you whether we should, for example, increase the load capacity of the vehicle, reduce the number of seats or remove optional equipment before delivering the vehicle.
The technically permissible maximum laden mass of the vehicle and the technically permissible maximum mass on the axle must not be exceeded.
Detailed information & explanations on the subject of weight and the configuration of the vehicle can be found in the section Legal information..
360° view of the CV600
CV600 standard specification
Always prepared: This camper’s compact exterior makes it suitable for everyday use, but it’s still always ready for when the next holiday comes.
Extremely comfortable camper van: Cosy seating arrangement with swivelling driver and passenger seats, handy USB sockets and a functional table.
Wake up to panoramic views: When you wake from a peaceful night’s sleep on the high-quality mattress, simply open up the rear doors for a spectacular morning view.
Cooking made fun in a Carado: Two-burner gas hob with Piezo ignition, fridge and ample worktop space. Bon appetit!
This is how to do compact: A bathroom with fixed wash basin, handy storage spaces and spacious shower cubicle all in one unit.
With the ISOFIX for two seats fitted as standard, child seats can be easily and particularly firmly anchored in the vehicle. In addition, the empty child seat is also secured during the journey. The ISOFIX child seat anchorage increases the safety of your child while driving.
The interior lighting is equipped with LED lights as standard. This saves power consumption and increases battery life. As LEDs do not get hot, they also offer increased fire and accident safety.
The kitchen drawers provide safe storage within easy reach. In addition, all drawers have a practical Servo Soft pull-in mechanism.
Detail view of the CV600
