Floor plan of the CV600

Technical Information CV 600

  • Series chassis FIAT
  • Basic motorization 2,3 l MJet
  • kw (PS) 88 (120)
  • Total length approx. cm 599
  • Total width approx. cm 205
  • Total height approx. cm 265
  • Headroom in living area, approx. cm 190
  • Wheel base approx. mm 404
  • Mass in running order approx. kg 2700
  • Maximum load approx. kg 600
  • Technically permissible total mass, kg 3300
  • Permissible towed load braked kg 2500 / ungebremst 750 kg
  • Permitted number of persons 4
  • Bed dimension: Central / middle bed, L x W, approx. cm 185 x 105 / 88 (OPT)
  • Bed dimension: Rear bed, L x W, approx. cm 197 x 157 / 150
  • Sleeping places 2 / 3 (OPT)
  • Refrigerator volume incl. freezer, approx. l 90
  • Heating type Combi 4
  • Fresh water supply, approx. l 100
  • Waste water tank approx. l 90
  • Second battery, Ah, incl. additional charger 95 / 18 Ah/A
  • Sockets 12 V 1
  • Sockets 230 V 3
  • Sockets USB 1

CV 600 standard specification

Body and storage space
Living room
Sleeping area
Body and storage space

Always prepared: This camper’s compact exterior makes it suitable for everyday use, but it’s still always ready for when the next holiday comes.

Living room

Extremely comfortable camper van: Cosy seating arrangement with swivelling driver and passenger seats, handy USB sockets and a functional table.

Sleeping area

Wake up to panoramic views: When you wake from a peaceful night’s sleep on the high-quality mattress, simply open up the rear doors for a spectacular morning view.


Cooking made fun in a Carado: Two-burner gas hob with Piezo ignition, 90 l capacity fridge and ample worktop space. Bon appetit!


This is how to do compact: A bathroom with fixed wash basin, handy storage spaces and spacious shower cubicle all in one unit.
